Commercial Cast Iron Disc Base (Ø50cm x H72cm)

Heavy-duty commercial cast iron round disc table base engineered for high-traffic restaurants, cafes, and hospitality venues.
Features solid ASTM gray iron casting, continuous center tie-rod, and adjustable floor glides for permanent wobble-free stability.
Zero-Wobble Foundation: High-density base casting with low center of gravity ensures absolute stability even under uneven edge loads.
Heavy Continuous Tie-Rod: Heavy-gauge through-rod connects the top mounting spider directly to the base bottom, eliminating joint flexing over year...

Quick Technical Data

Model Code CL-CI-01

Material Solid Cast Iron (ASTM A48 Gray Iron)

Dimensions Base Ø500mm x Height 720mm (Custom heights available)

Finish 180A High-Adhesion Textured Matte Black Powder Coating

MOQ 50 sets

Category Cast Iron

Request Bulk Quote Chat on WhatsApp Download Full Catalog (PDF)

* Minimum order: 50 sets for standalone LCL; or mix freely within a 20GP/40HQ container. Sample orders dispatch in 3-5 working days.

Direct Factory Price 0 Trading Middlemen

25 FCL Monthly Fast Global Container Sailing

QC Inspection SGS / BV Audits Accepted

Description
Technical Specifications

Description

Heavy-duty commercial cast iron round disc table base engineered for high-traffic restaurants, cafes, and hospitality venues. Features solid ASTM gray iron casting, continuous center tie-rod, and adjustable floor glides for permanent wobble-free stability.

Key Engineering & Structural Advantages

Zero-Wobble Foundation: High-density base casting with low center of gravity ensures absolute stability even under uneven edge loads.
Heavy Continuous Tie-Rod: Heavy-gauge through-rod connects the top mounting spider directly to the base bottom, eliminating joint flexing over years of daily commercial use.
Precision Floor Glides: Equipped with industrial M8 leveling glides with non-marring nylon bottoms to protect wood and tile floors.
Optimized KD Flat-Packing: Engineered for space-efficient container loading, minimizing ocean freight cost per set.

Technical Specifications

Model / SKU	CL-CI-01
Category	Cast Iron Table Base
Core Material	Solid Cast Iron (ASTM A48 Gray Iron)
Dimensions	Base Ø500mm x Height 720mm (Custom heights available)
Column / Profile	Heavy-gauge steel column tube Ø76mm x 1.5mm wall thickness
Mounting Spider	Cast iron cross spider mounting plate 300x300mm
Surface Finish	180A High-Adhesion Textured Matte Black Powder Coating
Net Weight	16.0 kg net weight
Export Packaging	KD Flat-Pack: Top plate 5pcs/ctn, column tube 10pcs/ctn, base disc 2pcs/ctn
Carton CBM	0.012 m³ / set
Container Loading (20GP)	2,100 sets / 20GP container \| 4,500 sets / 40HQ
Minimum Order Quantity (MOQ)	50 sets

B2B OEM / Customization Capabilities

Foshan Kailuo Furniture Co., Ltd. (CarloJP) provides comprehensive OEM/ODM manufacturing support for commercial project contractors, furniture importers, and restaurant chains worldwide:

Custom Heights: Standard dining (720mm), bar height (1050mm), cocktail height (900mm), or custom architectural heights.
Powder Coating & Finishes: Custom RAL powder coat colors, textured matte black, distressed bronze, electroplated titanium gold, and brushed satin stainless.
Drop-Ship Packaging: ISTA 3A certified mail-order drop-test carton packaging with custom barcode & branding labels.

Additional information

Material	Solid Cast Iron (ASTM A48 Gray Iron)
Dimensions	Base Ø500mm x Height 720mm (Custom heights available)
Finish	180A High-Adhesion Textured Matte Black Powder Coating
MOQ	50 sets
